MINISCAN IRXpert Gasoline and Diesel Analyzer
Standards Property Prediction based on : ASTM D5845, D6277, EN 238, EN 14078, ISO 15212, ASTM D86, D323, D5191, D6378, D613, D2699, D2700, ISO 3405, 5163, 5164, 5165, EN 13016
Intelligent Portable Multi-Fuel Analyzer
The MINISCAN IRXpert is the first completely portable multi-fuel analyzer for Gasoline, Diesel and Biofuel Blends, which combines the advantages of mid-IR and near-IR spectroscopy for utmost measurement accuracy. More than 40 fuel parameters are accurately determined by scanning the complete spectrum with superior resolution. Based on Grabner Instruments profound knowledge in fuel analysis, the MINISCAN IRXpert is designed as an intelligent, self-learning analyzer. At the push of a button the instrument automatically analyzes new fuel parameters.The MINISCAN IRXpert is a temperature controlled, robust and user friendly spectrometer for the automatic measurement of concentration of the most important components of gasoline and diesel. Advanced chemometrics, a worldwide database of calibration samples and information derived from the NIR spectrum provide highly reliable results for key properties such as Octane and Cetane Numbers, Distillation Properties and Vapor Pressure. An integrated temperature controlled density meter allows for exact determination and stability of fuel density.
Thiết bị phân tích các chỉ tiêu về xăng, diesel và nhiên liệu sinh học
Chỉ tiêu phân tích :
Chỉ tiêu đo mẫu xăng :
Thiết bị phân tích được thành phần các chất
Các chỉ tiêu đo mẫu dầu:
IROX 2000 Gasoline Analyzer
Portable Gasoline Analysis with MID-FTIR
IROX is an extremely compact, robust and user friendly Mid-FTIR spectrometer for the automatic measurement of the concentration of the most important components of gasoline. Thanks to an improved mathematical model and the use of a built-in density meter, the instrument additionally provides most reliable results for key properties such as Octane Numbers, Distillation Properties and Vapor Pressure.
IROX Diesel Analyzer
Portable Diesel Analysis with MID-FTIR
IROX Diesel is a Mid-FTIR analyzer dedicated to Diesel analysis: With a different spectrometer cell, its own on-board software and a vast calibration library handling is as easy as with the gasoline unit. This instrument also uses an improved calculation model, based on Cluster analysis and MLR for the determination of the key properties of diesel fuel such as Cetane Number, Cetane Index and Distillation Properties.
